| KLA15型 平衡重式电动叉车 | ||||
Performance （性能） | Model（型号） | KLA15 | ||
| 负载能力Maximum load capacity | kg | 1500 | ||
| 载荷中心距with load center at | Q | mm | 500 | |
| 起升高度Maximum lifting height | H3 | mm | 2500 | |
| 倾斜角度Tiltiing angle (up/down) | CDdegree | 0.6 | ||
| 无负载行驶速度Travel speed (without load) | km/h | 5 | ||
| 负载行驶速度Travel speed (with load) | km/h | 4 | ||
| 无负载起升速度Lifting speed (without load) | mm/s | 180 | ||
| 负载起升速度Lifting speed (with load) | mm/s | 100 | ||
| 无负载最大爬坡能力Ascend slope ability (without load ) | % | 8 | ||
| 负载最大爬坡能力Ascend slope ability (with load ) | % | 5 | ||
| 不带踏板最小转弯半径Minimum turning radius (without platform) | Wa | mm | 1560 | |
| 带踏板最小转弯半径Minimum turning radius (with platform) | Wa1 | mm | 1960 | |
Dimensions （尺寸） | 整车长度Overall length of frame | L | mm | 2712 |
| 整车宽度Overall width of frame | B | mm | 850 | |
| 门架降至最低高度Mast lowered height | H1 | mm | 1770 | |
| 门架起升至最高整车高度Max height(mast lifted with backrest) | H4 | mm | 3050 | |
| 轴距Wheelbase | Y | mm | 1220 | |
| 货叉长度Fork length | mm | 1070 | ||
| 货叉外侧距Fork spread width | mm | 200-725 | ||
| 货叉厚度Fork thickness | mm | 100 | ||
| 货叉降至最低高度Fork lowered height | S | mm | 40 | |
Tire （轮胎） | 承载轮Front wheel | mm | 210*55 | |
| 驱动轮Drive wheel | mm | 230*75 | ||
| 平衡轮Caster wheel | mm | 130*55 | ||
| 车轮类型Wheel material | polyurethane（聚氨酯） | |||
Electrical components （动力形式） | 驱动电机类型Drive motor type | AC series motor(交流电机） | ||
| 功率 Rated output | 9 | kw | 1.2 | |
| 起升电机类型Hoist motor type | DC series motor（直流电机） | |||
| 功率 Rated output | kw | 2.2 | ||
battery （电池） | 电压Voltage | V | 24 | |
| 容量Capacity | AH | 210/240 | ||
| 重量Weight | kg | 195/225 | ||
