| 1 | 名称Description | 前移式蓄电池叉车 | ||
| 2 | 型号Model | TF15-30 | TF20-30 | TF25-30 |
| 3 | 最大起升重量KgLoad capacity | 1500 | 2000 | 2500 |
| 4 | 载荷中心mm Load center | 500 | 500 | 500 |
| 5 | 最大起升高度mm Max. lifting height | 3000 | 3000 | 3000 |
| 6 | 门架倾角deg Tilting angle (forward- backward) | 3/5 | 3/5 | 3/5 |
| 7 | 轮胎配置Wheel type | 聚胺脂实心胎Polyurethane solid tire | ||
| 8 | 门架前移距离mmMast forwarding length | 560 | 675 | 675 |
| 9 | 货叉尺寸（LxWxT）mm Fork size | 1070x100x35 | 1070x122x40 | 1070x122x40 |
| 10 | 货叉调节范围mm Fork spread | 220-740 | 265-790 | 265-790 |
| 11 | 全长（含货叉）mm Overall length(with forks) | 2240 | 2450 | 2450 |
| 12 | 全宽mm Overall width | 1098 | 1258 | 1258 |
| 13 | 门架闭合时高度mm Overall height mast closed | 2100 | 2100 | 2100 |
| 14 | 货叉起升时最大高度（含挡货架）mm Overall height fork raised(with backrest) | 3900 | 3900 | 3900 |
| 15 | 护顶架高度mmOverhead guard height | 2320 | 2320 | 2320 |
| 16 | 转弯半径（外侧）mm Outside turning radius | 1615 | 1965 | 1965 |
