电动叉车型号 |
|
CPD35 |
制造商 Manufacturer |
|
BYD |
驱动 Driver |
|
电动 |
操纵形式 Operator type |
|
乘驾式 |
负载能力 Load capacity/rated load |
kg |
3500 |
载荷中心距 Load center |
mm |
500 |
悬距 Load distance,center of support arm wheel to face of forks |
mm |
475 |
轴距 Wheelbase |
mm |
1795 |
总重(含电池) Service weight including battery |
kg |
5380 |
轴负载(加负载) Axle load,with load,driver/castor/fork wheel |
kg |
7937.1/942.9 |
轴负载(无负载) Axle load,without load,driver/castor/fork wheel |
kg |
2353.75/3026.25 |
前轮型号 Wheel size ,front |
mm |
28X9-15 |
后轮型号 Wheel size ,rear |
mm |
23X9-10 |
前/后轮数量(x=驱动轮) Wheels,number front /rear(x=driven wheels) |
|
2x/2 |
前轮距 Track width,front |
mm |
1028 |
后轮距 Track width,rear |
mm |
980 |
全长 Overall length |
mm |
3600 |
全长(不计货叉) Length of face of forks |
mm |
2530 |
总宽 Overall width |
mm |
1320 |
货叉起升高度 Fork height |
mm |
3000 |
作业时门架最大高度 Max height |
mm |
4220 |
门架缩回时最低高度 Min height |
mm |
2240 |
护顶架高度 Overhead guard height |
mm |
2230 |
货叉尺寸 厚度/宽度/长度 Fork dimensions |
s/e/l mm |
1070×122×50 |
货叉外边距 Width over forks |
mm |
1028 |
倾斜角度 Tilt range Before / after |
deg |
5/9 |
自由起升高度 Free Lift |
mm |
120 |
最小转弯半径 Minimum turing radius |
mm |
2060 |
最小离地间隙 Ground Clearance |
mm |
|
(负载/无负载)行驶速度 Travel speed,with/without load |
km/h |
18/20 |
(负载/无负载)起升速度 Lift speed,with/without load |
mm/s |
380/420 |
(负载/无负载)下降速度 Lift speed,with/without load |
mm/s |
|
(负载/无负载)最大爬坡能力 Max.gradeability,with/without load |
% |
15/15 |
行车制动 Service brake |
|
液力制动 |
驱动电机功率 Drive motor rating S2 60 min |
kW |
2×10 |
起升电机功率 Lift motor rating at S3 15% |
kW |
22 |
电池容量 Battery voltage/nominal capacity K5 |
V/Ah |
80/400 |
电池重量 Battery weight |
kg |
518 |
控制器型号 Type of drive control |
|
COMBI AC2 |
