5500 |
FIXED |
|
| Load Capacity At 24” Load Center / 610 mm |
5500 lbs / 2494 kg |
| Lift Height** | 120” / 3048 mm |
| Side Shift | 6” / 152 mm |
| Tilt | 8° forward 8° backward |
| Weight † | 5550 lbs / 2517 kg |
| Width* | 96” / 2438 mm |
| Length* Legs Extended (F.O.P.S. Folded) Legs Retracted (Less Forks) |
96” / 2438 mm 45” / 1143 mm |
| Height* ** Mast Lowered Mast Raised |
95” / 2413 mm 155” / 3937 mm |
| Truck Overhang* (Less Forks) | 45” / 1143 mm |
| Length Under Truck Platform* (Less Forks) |
31” / 787 mm |
| Shortest Turning Radius and Wheel Base, Legs Extended |
5, 6, 7, & 9 |
| Tires | 10-16.5 NHS 8 Ply Std. 33 x 12.50-15 NHS 8 Ply Opt |
| Engine | Kubota V 1505-T Turbo Diesel |
| Output | 46.5 HP @ 3000 RPM Gross Intermittent |
| Cylinders | 4 |
| Max Travel Speed | 8 mph / 13 kph |
| Drive | 3 Wheel Hydrostatic (with 1 brake per wheel) |
| Fork Carriage | I.T.A. Class II |
| Forks (Standard) | 4” x 1 1/2” x 46” (102 mm x 38.1 mm x 1168 mm) |
| Optional Forks | Available |
| Adjustable Forks | Standard 16” (406 mm) mounting |
| Posi-Traction, Manually Activated Hydraulic Diff Lock |
Same |
| Theft / Vandalism Deterrence, Operator’s Compartment, Folds and locks in inoperative position |
Same |
| Manual or Power Operated Hook Up Kits |
Available |
| Back Rest, Backup Alarm and Amber Strobe Light |
Available |
| Counter Balance Weight Kit | STD |
